Advantages
- Special industrial-type rolls supplied with obstacle detection system seamlessly integrated in to the automation controller GL1 KTS
- Infrared light curtain installed on the platform for safe vehicle parking
- Requires small depth for the shaft pit
- Covers space only from the one side of the shaft area
- Costs less than the shears technology car lifting system
- Each case is studied and designed specifically by the Engineering Department of KLEEMANN
- Easy and quick installation
- CE marking and complete EC type examination certificate by Liftinstituut
- Technical support and guarantee by KLEEMANN
Specifications
| Model | KTS 2200 | KTS 3000 |
| Rated Load (Kg) | 2200 | 3000 |
| Max Travel (m) | 12000mm | 10000mm |
| Stops | max 4 | max 4 |
| Platform | max 2440*5500mm | max 2440*5500mm |
| Speed | max 0,15m/sec | max 0,15m/sec |
| Pit depth (mm) | min 400mm | min 500mm |
| Headroom (mm) | min 2700mm | min 2700mm |
| Motor | 9,5Kw/380V/50Hz | 12Kw/380V/50Hz |
| Pistons | KZAC 100X5 / KZAC 100X8,5 | KZAC 100X7 |
| Tank | Kleemann T150 | Kleemann T250 |
| Controller | KTS GL-1 | KTS GL-1 |
| Block of valves | Blain KV1S | Blain KV1S |
| Landing doors | Roller shutters with 3-phase external motor | Roller shutters with 3-phase external motor |
| Complies with | Machinery Directive2006/42/EC - EC typeexamination certificate | Machinery Directive2006/42/EC - EC typeexamination certificate |
